Smarti Foldable Scooter

SKU: 5806-1-1 Categories: ,

Description



Smarti Features
Weight Carrying Capacity: 120kg.
Weight W/Battery: 25kg
Weight W.O/Battery: 24kg
Size when folded for transportation: H 640mm x W 450mm x D 450mm.
Seat Size: H 380mm (from floor of scooter to top of seat) x W 430mm x D 400mm
Drive Wheel: 175mm (Solid)
Front Wheel: 150mm (Solid)
Rear Wheel Drive System: Sealed Transaxle direct Drive.
Max Curb Height: 25mm
Batteries: 1 x 24V x 10 ah Lithium Battery. Lithium Batteries now have MSDS Certificate which makes them safe for flight.
(ASK ABOUT AN UPGRADE TO A 2ND BATTERY PACK SPARE)
Charger: 2ah Off Board Lithium (optional)
Pre Charge Running Distance: Up to 15km. Add a 2nd battery to get up to 30KM per usage.
Controller: S-Drive 45A
Motor: 120 Watt
Motor Output: 120W x DC24V
Braking Distance: Max Speed Forward 1.2M
Slope Grade Ability: 8 deg depending on terrain and load weight.



Specifications

Model No. Mobie Maximum User Weight 120kg
Class 2 Battery Size 1 x 24V x 10 ah Lithium
Length 930mm (unfolded) Range 15km per Charge
Width 450mm Weight W/Battery 25kg
Height 865mm Features Automatic Folding & Unfolding
Seat Width 0.43m (17in) Maximum Speed 3.7 mph
Controller S-Drive 45A Front Wheel Size 150mm (Solid)
Seat Height (from the ground) 0.56m (22in) Rear Wheel Size 175mm (Solid)
Armrest Height Adjustable Turning Radius 820mm
Backrest Height Adjustable Charger 2ah Off Board Lithium (opt)
Max Curb Height 25mm Ground Clearance 36mm
Folded Dimensions H 640mm x W 450mm x D 450mm Colour Red & Blue
Safe Working Slope 6 ͦ
