Description
|
Smarti Features
|
| Weight Carrying Capacity: 120kg. |
| Weight W/Battery: 25kg |
| Weight W.O/Battery: 24kg |
| Size when folded for transportation: H 640mm x W 450mm x D 450mm. |
| Seat Size: H 380mm (from floor of scooter to top of seat) x W 430mm x D 400mm |
| Drive Wheel: 175mm (Solid) |
| Front Wheel: 150mm (Solid) |
| Rear Wheel Drive System: Sealed Transaxle direct Drive. |
| Max Curb Height: 25mm |
| Batteries: 1 x 24V x 10 ah Lithium Battery. Lithium Batteries now have MSDS Certificate which makes them safe for flight. |
| (ASK ABOUT AN UPGRADE TO A 2ND BATTERY PACK SPARE) |
| Charger: 2ah Off Board Lithium (optional) |
| Pre Charge Running Distance: Up to 15km. Add a 2nd battery to get up to 30KM per usage. |
| Controller: S-Drive 45A |
| Motor: 120 Watt |
| Motor Output: 120W x DC24V |
| Braking Distance: Max Speed Forward 1.2M |
| Slope Grade Ability: 8 deg depending on terrain and load weight. |
Specifications
| Model No. | Mobie | Maximum User Weight | 120kg |
| Class | 2 | Battery Size | 1 x 24V x 10 ah Lithium |
| Length | 930mm (unfolded) | Range | 15km per Charge |
| Width | 450mm | Weight W/Battery | 25kg |
| Height | 865mm | Features | Automatic Folding & Unfolding |
| Seat Width | 0.43m (17in) | Maximum Speed | 3.7 mph |
| Controller | S-Drive 45A | Front Wheel Size | 150mm (Solid) |
| Seat Height (from the ground) | 0.56m (22in) | Rear Wheel Size | 175mm (Solid) |
| Armrest Height | Adjustable | Turning Radius | 820mm |
| Backrest Height | Adjustable | Charger | 2ah Off Board Lithium (opt) |
| Max Curb Height | 25mm | Ground Clearance | 36mm |
| Folded Dimensions | H 640mm x W 450mm x D 450mm | Colour | Red & Blue |
| Safe Working Slope | 6 ͦ |
